Product Description



1.Product Introduction of Automatic Vertical Insulating Glass Washing and Drying Machine
Automatic Vertical Insulating Glass Washing and Drying Machine  is the first step of making insulating glass, the washing ability and quality decides the ability and quality of the final finished insulating glasses. To make sure to get high work efficiency, we adopts the vertical glass washing structure, easy to operate together with the insulating glass lines, and also save the workshop places.

Automatic Vertical Insulating Glass Washing and Drying MachineAutomatic Vertical Insulating Glass Washing and Drying Machine


Detailed Photos





2.The advantages of Automatic Vertical Insulating Glass Washing and Drying Machine

2.1.The whole washing section are made of stainless steel;
2.2.Converter driving for Low-E brush rotatory speed;
2.2.Automatically distinguish the coating side of coated glass and Low-E glass;
2.2.Upper part of washing box use the bevel gear connects; Washing machine adopts oil less bearing.

Automatic Vertical Insulating Glass Washing and Drying Machine
Product Parameters




3.Technical Parameter of Automatic Vertical Insulating Glass Washing and Drying Machine

ModelPower SupplyAir PressureMax Glass SizeMin Glass SizeGlass ThicknessConveying SpeedCleaning SpeedOverall Dimension
QXJ-1800380V, 50HZ,
18KW
0.6-0.8
MPA
1800*2350
mm
260*450
mm
3-30mm0-50
meter/min
2-12
meter/min
6800*1800*2750
mm
QXJ-2000380V, 50HZ,
 21KW
0.6-0.8
MPA
2000*2500
mm
260*450
mm
3-30mm0-50
meter/min
2-12
meter/min
7800*1800*2950
mm
QXJ-2500380V, 50HZ,
 24KW
0.6-0.8
MPA
2500*3150
mm
260*450
mm
3-30mm0-50
meter/min
2-12
meter/min
9200*2300*3500
mm

Automatic Vertical Insulating Glass Washing and Drying Machine
Our Advantages




4.Products Feature of Automatic Vertical Insulating Glass Washing and Drying Machine

4.1Conveying section:
4.1.1The whole machine adopts vertical inclined structure, conveying stable, and easy for loading big glasses.
4.1.2The backrest wheel adopts inlaid design and mounting bearings, which is firm and durable, runs smoothly, and has no damage or scratches to the glass.
4.1.3The body steel frame uses National standard square tube, this is the strong base of the machine working stable.

4.2Washing and drying section
4.2.1The backrest plate is made of special material, durable, and with high water resistance, we have already made waterproof test.
4.2.2The whole washing and drying section are made of stainless steel, built-in 3 pairs of brushes, 4 or 6 pairs of rubber roller design. One motor independently drives one brush, which is better to clean coated glasses and LOW-E glass.
4.2.3We are using gear driven inside of the washing room, so that it is more stable during processing small glass.
Automatic Vertical Insulating Glass Washing and Drying Machine
Company Profile





Automatic Vertical Insulating Glass Washing and Drying Machine

5: What is the service can you supply on Automatic Vertical Insulating Glass Washing and Drying Machine  ?
5.1. Machine function introduction and quotation reply within 24 hours.
5.2.Industrial design or workshop layout design reply within 48 hours.
5.3.Customization feasibility reply within 72 hours.
5.4.Engineer onsite installation and operation guide if necessary.
5.5.Machine operation and maintenance guide service after sells.
5.6.Supply all the parts of the machine in whole lifetime.
5.7.PLC control system can be update and repaired in machine's whole lifetime!
5.8.Spare parts supplied in cost prices for all the clients.
