Horizontal Glass Washing And Drying Machine
Main function and features:
1 transmission rollers adopt diameter of 85mm durable rubber rollers
2 main transmission adopts bevel gear drive with frequency control and digital display. The upper and lower brushes are driven separately by three motors(upper two, lower one)through belt driving to ensures smooth rotation speed with high cycle life.
3 top frame of both washing and drying sections equipped with high strength screw can be elevated by 400mm as a whole, easy to operate, for the convenience of cleaning and maintaining.
4 three pairs of brushes(diameter is 160mm), of which shafts are processed with stainless steel material, can wash hard and soft Low-e glass, normal coated glass and sunshine coated glass.
5 it is especially suitable for supporting use of glass tempering furnace, screen printing line, laminating line and other equipment on highly demanding for cleaning and drying effect.
Main technical parameter:
Max width of glass
|Min length of glass||300*300mm|
|Glass conveyor speed||0.6-6.5m/min|
|Height of operation platform||880mm|
